CNC Lathe Sleeves
| SLEEVES FOR CNC LATHE :: STRAIGHT SHANK :: | ||||||||
 |
||||||||
| Code | D1 | D2 | d1 | d2 | L1 | L2 | L3 | FIG No. |
| CYL 40/8 | 40 | 47 | 8 | 10 | 85 | 45 | 5 | 1 |
| CYL 40/10 | 40 | 47 | 10 | 12 | 85 | 45 | 5 | 1 |
| CYL 40/12 | 40 | 47 | 12 | 14 | 85 | 45 | 5 | 1 |
| CYL 40/16 | 40 | 47 | 16 | 18 | 85 | 35 | 5 | 2 |
| CYL 40/20 | 40 | 47 | 20 | - | 90 | - | 5 | 3 |
| CYL 40/25 | 40 | 47 | 25 | - | 90 | - | 5 | 3 |
| CYL 40/32 | 32 | 40 | 32 | - | 90 | - | 5 | 3 |
| CYL 32/8 | 32 | 40 | 8 | 10 | 85 | 45 | 5 | 1 |
| CYL 32/10 | 32 | 40 | 10 | 12 | 85 | 45 | 5 | 1 |
| CYL 32/12 | 32 | 40 | 12 | 14 | 85 | 45 | 5 | 1 |
| CYL 32/16 | 32 | 40 | 16 | 18 | 85 | 35 | 5 | 2 |
| CYL 32/20 | 32 | 40 | 20 | - | 90 | - | 5 | 3 |
| CYL 32/25 | 32 | 40 | 25 | - | 90 | - | 5 | 3 |
| MT SHANK :: | ||||||||
| Code | D1 | D2 | d | L1 | L2 | L3 |  |
|
| CYL40/MTA1 | 40 | 47 | 12.065 | 85 | 56 | 5 | ||
| CYL40/MTA2 | 40 | 47 | 17.78 | 95 | 67 | 5 | ||
| CYL40/MTA3 | 40 | 47 | 23.825 | 115 | 84 | 5 | ||
| CYL32/MTA1 | 32 | 40 | 12.065 | 85 | 56 | 5 | ||
| CYL32/MTA2 | 32 | 40 | 17.78 | 95 | 67 | 5 | ||
| CYL32/MTA3 | 32 | 40 | 23.825 | 115 | 84 | 5 | ||
