Face and Shoulder Mill Arbour (FMC)
| FACE AND SHOULDER MILL ARBOUR ( FOR CUTTER DIA < 160 MM ) | |||||||
 |
|||||||
| Code | D | L | L1 | D1 | C1 | G | Cutter Dia D2 |
| BT30/FMC16/45 | 16 | 45 | 14 | 35 | 13 | M8 | 40 |
| BT30/FMC22/45 | 22 | 45 | 19 | 40 | 16 | M10 | 50&63 |
| BT30/FMC27/45 | 27 | 45 | 21 | 48 | 18 | M12 | 80 |
| BT40/FMC16/45 | 16 | 45 | 14 | 35 | 13 | M8 | 40 |
| BT40/FMC22/60 | 22 | 60 | 19 | 40 | 16 | M10 | 50&63 |
| BT40/FMC22/90 | 22 | 90 | 19 | 40 | 16 | M10 | 50&63 |
| BT40/FMC27/60 | 27 | 60 | 21 | 48 | 18 | M12 | 80 |
| BT40/FMC27/90 | 27 | 90 | 21 | 48 | 18 | M12 | 80 |
| BT40/FMC32/60 | 32 | 60 | 24 | 58 | 42 | M16 | 100 |
| BT40/FMC32/75 | 32 | 75 | 24 | 58 | 42 | M16 | 100 |
| BT40/FMC40/60 | 40 | 60 | 26 | 70 | 52 | M20 | 125 |
| BT50/FMC22/75 | 22 | 75 | 19 | 40 | 16 | M10 | 50&63 |
| BT50/FMC22/120 | 22 | 120 | 19 | 40 | 16 | M10 | 50&63 |
| BT50/FMC22/150 | 22 | 150 | 19 | 40 | 16 | M10 | 50&63 |
| BT50/FMC27/90 | 27 | 90 | 21 | 48 | 18 | M12 | 80 |
| BT50/FMC27/150 | 27 | 150 | 21 | 48 | 18 | M12 | 80 |
| BT50/FMC32/75 | 32 | 75 | 24 | 58 | 42 | M16 | 100 |
| BT50/FMC32/105 | 32 | 105 | 24 | 58 | 42 | M16 | 100 |
| BT50/FMC40/75 | 40 | 75 | 26 | 70 | 52 | M20 | 125 |
| BT50/FMC40/105 | 40 | 105 | 26 | 70 | 52 | M20 | 125 |
