Side and Face Mill Arbour
| SIDE & FACE MILL ARBOR :: | |||||||
 |
|||||||
| Code | D | L | H | H1 | C | W | G |
| BT40/SCA 13/75 | 13 | 75 | 120 | 17 | 20 | - | M12 x 1.25 |
| BT40/SCA 13/105 | 13 | 105 | 150 | 17 | 20 | - | M12 x 1.25 |
| BT40/SCA 16/75 | 16 | 75 | 121 | 23 | 26 | 4 | M14 x 1.5 |
| BT40/SCA 16/105 | 16 | 105 | 151 | 23 | 26 | 4 | M14 x 1.5 |
| BT40/SCA 22/75 | 22 | 75 | 126 | 29 | 34 | 6 | M20 x 1.5 |
| BT40/SCA 22/120 | 22 | 120 | 171 | 29 | 34 | 6 | M20 x 1.5 |
| BT40/SCA 27/75 | 27 | 75 | 130 | 32 | 40 | 7 | M24 x 2 |
| BT40/SCA 27/120 | 27 | 120 | 175 | 32 | 40 | 7 | M24 x 2 |
| BT40/SCA 32/90 | 32 | 90 | 150 | 41 | 46 | 8 | M30 x 2 |
| BT45/SCA 13/75 | 13 | 75 | 120 | 17 | 20 | - | M12 x 1.25 |
| BT45/SCA 13/105 | 13 | 105 | 150 | 17 | 20 | - | M12 x 1.25 |
| BT45/SCA 16/90 | 16 | 90 | 136 | 23 | 26 | 4 | M14 x 1.5 |
| BT45/SCA 16/120 | 16 | 120 | 166 | 23 | 26 | 4 | M14 x 1.5 |
| BT45/SCA 22/90 | 22 | 90 | 141 | 29 | 34 | 6 | M20 x 1.5 |
| BT45/SCA 22/135 | 22 | 135 | 186 | 29 | 34 | 6 | M20 x 1.5 |
| BT45/SCA 27/190 | 27 | 90 | 145 | 32 | 40 | 7 | M24 x 2 |
| BT45/SCA 27/135 | 27 | 135 | 190 | 32 | 40 | 7 | M24 x 2 |
| BT45/SCA 32/90 | 32 | 90 | 150 | 41 | 46 | 8 | M30 x 2 |
| BT45/SCA 32/135 | 32 | 135 | 195 | 41 | 46 | 8 | M30 x 2 |
| BT50/SCA 13/75 | 13 | 75 | 120 | 17 | 20 | - | M12 x 1.25 |
| BT50/SCA 13/105 | 13 | 105 | 150 | 17 | 20 | - | M12 x 1.25 |
| BT50/SCA 16/90 | 16 | 90 | 136 | 23 | 26 | 4 | M14 x 1.5 |
| BT50/SCA 16/120 | 16 | 120 | 166 | 23 | 26 | 4 | M14 x 1.5 |
| BT50/SCA 22/90 | 22 | 90 | 144 | 29 | 34 | 6 | M20 x 1.5 |
| BT50/SCA 22/135 | 22 | 135 | 186 | 29 | 34 | 6 | M20 x 1.5 |
| BT50/SCA 27/90 | 27 | 90 | 145 | 32 | 40 | 7 | M24 x 2 |
| BT50/SCA 27/135 | 27 | 135 | 190 | 32 | 40 | 7 | M24 x 2 |
| BT50/SCA 32/90 | 32 | 90 | 150 | 41 | 46 | 8 | M30 x 2 |
| BT50/SCA 32/135 | 32 | 135 | 195 | 41 | 46 | 8 | M30 x 2 |
| BT50/SCA 40/90 | 40 | 90 | 156 | 46 | 55 | 10 | M36 x 3 |
| BT50/SCA 40/135 | 40 | 135 | 201 | 46 | 55 | 10 | M36 x 3 |
