R8 Shank Collet Chucks
| TAPPING COLLET CHUCK - BT SHANK :: | |||||||
 |
|||||||
| Code | Suitable Collet | Collet Capacity | L1 | Nut | Spanner | ||
| BT40/CTTC/ER16 | ER16 | 0.5-10 | 90 | UM/ER16 | GS 25 | ||
| BT40/CTTC/ER20 | ER20 | 1.0-13 | 90 | UM/ER20 | GS 30 | ||
| BT40/CTTC/ER25 | ER25 | 1.0-16 | 100 | UM/ER25 | E 25 | ||
| TAPPING COLLET CHUCK - STRAIGHT SHANK :: | |||||||
 |
|||||||
| Code | Suitable Collet | Collet Capacity | D | L1 | L2 | Nut | Spanner |
| CTTC 20/ ER16/100 | ER16 | 0.5-10 | 20 | 100 | 75 | UM/ER16 | GS 25 |
| CTTC 20/ ER20/100 | ER20 | 1.0-13 | 20 | 100 | 75 | UM/ER20 | GS 30 |
| FEATURES:- | |||||||
| * Suitable for tapping M3 TO M12 | |||||||
| * Collets can be interchanged according to the shank size of tap. | |||||||
| * Compression & Tension ensure better thread form and accuracy on job | |||||||
| * Suitable only for turning & machining centres. | |||||||
| * Best-Suited for soft materials like Aluminium, Brass, Cast Iron, Etc. | |||||||
