Face and Shoulder Mill Arbour (FMB)
| FACE & SHOULDER MILL ARBOR ( FOR CUTTER DIA 160 - 150 MM ) :: | |||||||
 |
|||||||
| Code | D | L | L1 | D1 | P | G | Cutter DIA |
| BT40/FMB40F/65 | 40 | 65 | 30 | 90 | 66.7 | M12 | 160 |
| BT50/FMB40F/75 | 40 | 75 | 30 | 90 | 66.7 | M12 | 160 |
| BT50/FMB60/75 | 60 | 75 | 40 | 130 | 101.6 | M16 | 200-500 |
| DEEP SHOULDER MILL :: | |||||||
 |
|||||||
| Code | D | L | L1 | D1 | G | ||
| BT40/SMS32/70 | 32 | 70 | 24 | 58 | M16 | ||
| BT40/SMS40/70 | 40 | 70 | 27 | 70 | M20 | ||
| BT50/SMS32/90 | 32 | 90 | 24 | 58 | M16 | ||
| BT50/SMS40/90 | 40 | 90 | 27 | 70 | M20 | ||
| BT50/SMS50/90 | 50 | 90 | 30 | 90 | M24 | ||
