Micro Boring Bar

MICROBORE BORING BAR ::

FIG	Code	D		L	E	M	H	C	B	Cartridge	Aprx Wt (kg)	FIG	Code	D		L	E	M	H	C	B	Cartridge	Approx Weight (kg)
		Min	Max											Min	Max
1	BT40-BCA 13.5-105	13.5	16	105	8	67	15	44	13	M1B2F40	1.5	1	BT40-BCA 13.5-105	13.5	16	105	8	67	15	44	13	M1B2F40	1.5
	BT40-BCA 13.5-165			165	68						20		BT40-BCA 13.5-165			165	68						20
	BT40-BCA 14.5-105	14.5	17	105	8				14		1.5		BT40-BCA 14.5-105	14.5	17	105	8				14		1.5
	BT40-BCA 14.5-165			165	68						2		BT40-BCA 14.5-165			165	68						2
	BT40-BCA 16-105	16	22.5	105	2	73	18		15	M1A2F40	1.5		BT40-BCA 16-105	16	22.5	105	2	73	18		15	M1A2F40	1.5
	BT40-BCA 16-180			180	77						2		BT40-BCA 16-180			180	77						2
	BT40-BCA 19-120	19	23	120	4	86	23		18	M2B2F40	1.5		BT40-BCA 19-120	19	23	120	4	86	23		18	M2B2F40	1.5
	BT40-BCA 19-180			180	64						2		BT40-BCA 19-180			180	64						2
	BT40-BCA 23-135	23	29	135	-	105	24	-	22	M3B2F40	1.5		BT40-BCA 23-135	23	29	135	-	105	24	-	22	M3B2F40	1.5
	BT40-BCA 23-195			195	60			44			2		BT40-BCA 23-195			195	60			44			2
	BT40-BCA 29-150	29	41	150	5	115	30		28	M3A2F40	1.5		BT40-BCA 29-150	29	41	150	5	115	30		28	M3A2F40	1.5
	BT40-BCA 29-195			195	50						2		BT40-BCA 29-195			195	50						2
	BT40-BCA 38-150	38	49	150	5		41		35	M5B2F40	1.5		BT40-BCA 38-150	38	49	150	5		41		35	M5B2F40	1.5
	BT40-BCA 38-210			210	8	172			37		2.5		BT40-BCA 38-210			210	8	172			37		2.5
	BT40-BCA 46-150	46	66	150	5	115	45	55	41	M5A2F40	2.5		BT40-BCA 46-150	46	66	150	5	115	45	55	41	M5A2F40	2.5
	BT40-BCA 46-225			225	13	182			44		3		BT40-BCA 46-225			225	13	182			44		3
2	BT40-BCA 62-165	62	87	165	-	135	-	51	-	M7A2F80	3.5	2	BT40-BCA 62-165	62	87	165	-	135	-	51	-	M7A2F80	3.5
1	BT40-BCA 62-225			225	11	184	60	62	57		4.5	1	BT40-BCA 62-225			225	11	184	60	62	57		4.5
2	BT40-BCA 83-120	83	108	120	-	-	-	63	-		3.5	2	BT40-BCA 83-120	83	108	120	-	-	-	63	-		3.5
	BT40-BCA 83-165			165	-		-		-		4.5		BT40-BCA 83-165			165	-		-		-		4.5
	BT40-BCA 83-225			225	-		-		-		6		BT40-BCA 83-225			225	-		-		-		6
3	BT40-BCA 98-165	98	142	165	-	-	90	83	-	M10A2F80	6	3	BT40-BCA 98-165	98	142	165	-	-	90	83	-	M10A2F80	6
