Fine Boring Bar And Combination Boring Bar
| FINE BORING BAR :: |  |
||||||
 |
|||||||
| Code | D | D1 | L | Fig Ref. | Cartridge To Be Used | ||
| Min. | Max. | ||||||
| BT40/FBS 90-28/150 | 27 | 32 | 26 | 150 | 1 | R/L 148C - 11 - 0602 | |
| BT40/FBS 90-38/150 | 36.5 | 43.5 | 34.5 | 150 | 1 | R/L 148C - 12 - 0902 | |
| BT40/FBS 75-51/165 | 50.1 | 62.1 | 46.5 | 165 | 1 | R/L 148C - 23 - 1102 | |
| BT40/FBS 75-72/165 | 70.65 | 90.65 | 67 | 165 | 1 | R/L 148C - 24 - 16T3 | |
| BT40/FBA 90-26/150 | 24.8 | 28.8 | 22 | 150 | 2 | R/L 148C - 31 - 0602 | |
| BT40/FBA 90-33/150 | 32.5 | 38.1 | 28.5 | 150 | 2 | R/L 148C - 32 - 0902 | |
| BT40/FBA 75-44/150 | 43.5 | 53.1 | 38 | 150 | 2 | R/L 148C - 43 - 1102 | |
| BT40/FBA 75-62/165 | 60.8 | 76.8 | 55 | 150 | 2 | R/L 148C - 44 - 16T3 | |
